Vertical type automatic alcohol swab packaging machine

Features:

1:Machine is controlled by PLC programmable controller,sets parameters with touch screen panel .

2:Automatic liquid added system,under the premise of high liquid addition,the sealing is tight, no leakage, no foaming.

3:Raw material nonwoven vertical type function.

4:Machine is with high production 540pcs/min.

Machine process:

Loading nonwoven fabric and packaging film on machine → nonwoven fabric longitudinally folded (or not folded) → cut → add liquid → folded sheet output → bag making → packaging → sealing → output packaged finished products.

Machine data:

Machine name:Vertical type automatic alcohol swab packaging machine

Alcohol swab unfolding size: length 30mm × width 60mm

Alcohol swab folded size: length 30mm × width 30mm

Alcohol swab folding method: fold once, 2 layers

Product Bag size: length 50mm×width 50mm

Production capacity: 540pcs/min

Packaging film material size: 73-110g/m2 paper aluminum film composite wrapping paper

Packaging film specifications: Φ ≤ 350 mm, width 400 mm, paper core inner diameter 76.2mm(3inch)

Alcohol swab raw material size: 76.2mm(3inch)coiled, 30-60g/m2 nonwoven

Alcohol swab raw material specifications: diameter ≤ 600mm, width 60mm

Total power:5.5kw

Voltage:220v,50hz(option)

Equipment weight:800 kg

Dimensions: 2500×1000×1500mm(LWH)

Packing size:2700×1900×1800mm(LWH)

NOTE:ANY SPECIFICATIONS CAN BE CUSTOMIZED.
